1/16" Gray Acrylic Sheet

1/16" gray in practice

Transparent stock at 1/16" reads as a clean pane — you see the object behind it, not the material.

At this thickness the sheet flexes easily and is better thought of as a facing than a panel — it wants a frame or a backing behind it, and it will bow under its own weight over any real span.

In a laser: a CO2 machine cuts this cleanly and leaves a flame-polished edge. A diode laser will not cut it at any setting — the beam passes straight through transparent acrylic.

1/16" gray (color 2074) starts at $4.22 for a 12″ × 12″ piece at this thickness, and weighs about 0.37 lb per square foot, so a 24″ × 48″ piece comes to roughly 3 lb — worth knowing before you size a panel someone has to lift or ship.

Why 1/16" gray acrylic?

At 1/16″ acrylic stops behaving like a panel and starts behaving like a sheet — light, slightly flexible, and easy to cut, score and drill. It is the right call when weight or clearance matters more than rigidity: model making, layered inlays and shims, lightweight signage faces, glazing for small frames, and protective facings that need to sit almost flush. Anything free-standing or load-bearing wants 1/8″ or thicker. We cut 1/16″ to order rather than holding it in every colour, so the range at this thickness is a short one — clear, white, black and smoke gray; the colours offered are the ones listed on this page.
